AVK SMART WATER, VIDI POSITIONER

Status indicator for AVK S29/91 underground hydrants

Anthony Whittam AVK UK Network Water Specialist

Anthony Whittam

Head of Smart Water and Pressure Management

VIDI Positioner is a battery-operated device that detects the open/close position of a S29/91 underground hydrants and transmits data wirelessly.

VIDI Positioner is a smart device for indicating the position of a valve. It detects the open/close position of an underground hydrant and transmits data wirelessly. This VIDI Positioner is designed for the AVK S29/91 underground hydrant and installed in combination with an AVK stem cap.

After installation and activation, the device transmits information about the status of the underground hydrant to the VIDI Cloud platform that stores the data. VIDI Positioner provides accurate data directly from the network by regularly monitoring the status of the underground hydrant.

Variant 3002/100-001

Features

Positioner:

  • Communication: LoRa® (868MHz)
  • Detects the position of the underground hydrant and transmits data to the VIDI Cloud or a third-party software
  • Material: Robust plastic cover, IP68
  • Easy provisioning and configuration via NFC (app)
  • Operating temperature: -40 up to +65 °C
  • Fits on: AVK S29/91 underground hydrants
  • Accuracy: A quarter of a full turn (90°)
  • Transmits data immediately when the valve position change and retransmit the value after 5 min, 10 min, 1 hr, 6 hrs, 12 hrs, 24 hrs.
  • Transmits a keep-alive signal every 24 hrs if the position has not changed



Battery:

  • Embedded battery with a 10-year lifespan
  • Max. voltage output: 3.6 V
  • Size: 2x 1/2 AA-cell (NB-IoT and LoRa®)
  • Capacity / cell: 1200 mAh

Downloads

Datasheet
Installation, Operation & Maintenance
Product Brochure
Guidelines

Reference nos. and dimensions:

Scroll for more info
Ref. no. Communication
H3
mm
D
mm
F
mm
Theoretical
weight/kg
3002-100-001-000 LORA 102 74 28.5 0.1
3002-100-003-000 LORA 102 74 28.5 0.1
Enquiry
Scroll for more info

Components

1. Stem Cap Ductile iron GJS-500-7
2. Position indicator ASA plastic Luran S 778T
3. ASA plastic Luran S 778T
